R5905753 /17 DPxK-19B/23B/P138

Location of the covers

Image 10–1 Location of the covers

1 Lamp cover

2 Input cover

3 Front cover

4 Side cover

5 Rear cover

All cover can be individually removed.

Removal and installation of the projector covers
