147R5905753 /17 DPxK-19B/23B/P
2. Gently move the bottom side of the cover towards the projector and push the bottom side until the locking
studs click in the receivers.
Image 10–16 Secure input cover
3. Secure the cover by fastening the captive screw.
10.8 Installation of the lamp cover
Required tools
Flat screwdriver
How to install
1. Place the top side of the cover on its place.
Removal and installation of the projector covers
