R5905753 /17 DPxK-19B/23B/P144
10.5 Removal of the side cover
Required tools
Flat screwdriver
How to remove
1. Release both captive screws on top of the side cover.
Image 10–10 Captive screws
2. Push both lock to each other to release the locks and pull at the same time the bottom side of the cover
away form the projector.
Image 10–11 Unlock side cover
Removal and installation of the projector covers
