Integrated Media Block (IMB)
Image 6–8 Example of IMB powered by Dolby.
Integrated Media Server (IMS)
Image 6–9 Example of IMS powered by Dolby.
Configuration and operation instructions for IMB and IMS are not included in this document. See
manufacturers website of the installed IMB/IMS for technical documentation and support.
6.9 Cinema Controller of the DPxK-19B/23B/P
Location of the communication ports
PERIPHERAL PORT
WAN
LAN
GENERAL INTERFACE I/0USB 2.0DVI IN A
DVI IN B
RS 232 IN 3D INTERFACE
1 3 5 72 64
Image 6–10
Input & communication
