R5905753 /17 DPxK-19B/23B/P180

A.10 Dimensions of the universal pedestal

Dimensions

566,7

866,8

876,3

Image A–2 Dimensions given in millimeters.

A.11 Technical Regulations

Certificates

Image A–

3 EAC mark

Image A–4 CE

mark

Image A–5 CCC

mark

Image A–

6 CEBEC

mark
