Barco LCD 5521 V4 User Manual

5. Mechanical setup of display wall with pedestals
Pedestal
26
When the pedestal has been assembled, two ce
n-
tering pins R867885 have to be inserted into the
left and right vertical profile.
These centering pins ensure that the final struc-
ture will be perfectly aligned.
Pedestal
27
Hammer in the pins.
Pedestal
28
Make sure to align the pins with the top of the
profile!
Barco - LCD 5521 V4 - R591734 - Installation manual - Revision 00 - March-2017
_____________________________________________________________
39
