Barco MDSC-1119 Getting Started Guide

Technical information
39
MDSC-2124:
Item Specification
Resolution Native: 1920x1200
Display area (H x V) 518.4 x 324 (mm)
Viewing angle
(@ 10/1 contrast)
Vertical: 178º
Horizontal: 178º
Pixel Pitch 0.270 mm (H) x 0.270 mm (V)
Native color resolu-
tion
8 bits / sub-pixel
Luminance 320-400 cd/m²
Contrast ratio 700/1 (typical in dark environment)
Response time
(tf+tr)
5 ms typical (@ 25° C after 30 min warm-
up)
Digital video input
specifications
Complying to DVI Rev 1.0 specifications
DVI-I analog video
signal level
500-950 mV
DB15 analog video
signal level
500-950 mV
BNC analog video sig-
nal level
500-950 mV
Component video sig-
nal level
Y: 1000 mV
u, v: 700 mV
S-Video signal level Y: 1000 mV
C: 286 mV
Composite video sig-
nal levels
1000 mV

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
