Barco MDSC-1119 Getting Started Guide

Technical information
40
Input signals Possible resolutions:
• • 640 x 480 @ 60, 75, 85, 100 Hz
• • 800 x 600 @ 60, 75, 85, 100 Hz
• 1024 x 768 @ 60, 75, 85, 100 Hz
• 1024 x 1280 @ 59 Hz
• 1024 x 1280 @ 70 Hz
• 1152 x 864 @ 75 Hz
• 1152 x 870 @ 60, 85, 100 Hz
• 1280 x 1024 @ 60, 75, 85 Hz
• 1600 x 1200 @ 59 Hz
• 1200 x 1600 @ 59 Hz
• 1920 x 1200 @ 60 Hz
Power source Input for external power supply unit: 90 ~
264 VAC
Input for display: 24 VDC. (The supplied
power supply must be used)
Power consumption 130 Watt (max., at 90 VAC, maximum back-
light)
Dimensions unpacked
(W x H x D)
784 x 199 x 543 mm (without foot)
Dimensions packed 878 x 277 x 569 mm
Net weight
(unpacked, without
foot)
10,8 kg
Operating Tempera-
ture
0°C to 40°C, 15°C to 35°C within specs
Storage Temperature -20°C to 60°C
Humidity 20% - 85% (non-condensing) for operation
20% - 85% (non-condensing) for storage
Item Specification

Barco MDSC-1119 Specifications

Display Specifications

technology	TFT Active Matrix LCD
native resolution	1280 x 1024
active screen diagonal	19 inches
active screen area	14.8 x 11.9 inches
pixel pitch	0.294 mm
brightness	300 cd/m2
contrast ratio	700:1
viewing angle	178 degrees

Connectivity and Control

analog video inputs	1x universal 5BNC, VGA (DB15), S-Video (4-pin mini DIN), SDI (BNC)
digital video inputs	DVI-I
communication	RS232 (9-pin D-Sub)

Supported Resolutions and Formats

horizontal scan frequencies	15-100 kHz
vertical scan frequencies	50-120 Hz
bandwidth	165 MHz

Power Requirements

external DC power supply	90-264 VAC
display voltage	20-24 VDC
power consumption	80 Watt max

Physical Characteristics

display dimensions	427 x 356 x 81 mm
display weight	8 kg
mounting	75 & 100mm VESA
