K5902133 (451920612483)-02 MDSC-8255
30
5.1 Picture menu
5.1.1 Profile
About profiles
To select a profile means to load a set of predefined video parameters like Brightness, Contrast, Saturation,
Input selection (Primary & Secondary), Multi-image layout selection, etc.
The user can modify the default video parameters associated to each profile and save the new parameters
setting under the User 1, User 2 or User 3 profile. The Factory and X Ray profiles can be temporarily modified,
but the factory default can’t be overwritten and can always be recalled through the recall profile menu item.
The available profiles for your display are:
• Factory
• X Ray (by selecting this profile, Gamma and Color temperature will be automatically set to DICOM and
Native respectively)
• User 1
• User 2
• User 3
To select a profile
1. Bring up the OSD main menu.
2. Navigate to the Picture menu.
3. Enter the Profile submenu.
4. Select one of the available profiles and confirm.
5.1.2 Brightness
To adjust the brightness level
1. Bring up the OSD main menu.
2. Navigate to the Picture menu.
3. Enter the Brightness submenu.
The command bar Brightness is highlighted.
4. Set the brightness level as desired and confirm.
The selected brightness is maintained at a constant level by the automatic backlight stabilization
function.
The brightness level can also be adjusted through a shortkey function.
Brightness level is adjusted by controlling the backlight illumination only.
5.1.3 Contrast
To adjust the contrast level
1. Bring up the OSD main menu.
2. Navigate to the Picture menu.
3. Enter the Contrast submenu.
The command bar Contrast is highlighted.
4. Set the contrast level as desired and confirm.
Advanced operation
