Barco MDSC-8527 User Manual

27R5914634 /00 MDSC-8527
4.2 Picture advance menu
4.2.1 Input range
About input range
This command sets the video signal range. Suggest to set the input range according to the input signal range.
The available input ranges are:
• Full: Input range = 0–255
• Limited: Input range = 16–235
To select the input range
1. Bring up the OSD main menu.
2. Navigate to the Picture Advanced menu.
3. Enter the Input range submenu.
4. Select one of the available input ranges and confirm.
Input range 16–255 is possible when Gamma is set to “Video2” (see “Gamma”, page 26).
4.2.2 Image size
About image size
The available image sizes for your display are:
• Fill Aspect: Fill the screen on largest dimension, no modification in image aspect-ratio
• 1:1: Native image, no scaling
• Vert Fill
(*)
• Hor Fill
(*)
• Fill All
(*)
(*)
With modification of image aspect-ratio
To select the image size
1. Bring up the OSD main menu.
2. Navigate to the Picture Advanced menu.
3. Enter the Image Size submenu.
4. Select one of the available image sizes and confirm.
4.2.3 Zoom
This function is not available when DisplayPort mode is set to DP 1.2 MST.
To adjust the zoom level
1. Bring up the OSD main menu.
2. Navigate to the Picture Advanced menu.
3. Enter the Zoom submenu.
The zoom command bar is highlighted.
4. Adjust the zoom level as desired and confirm.
4.2.4 Pan
This function is not available when DisplayPort mode is set to DP 1.2 MST.
Advanced operation
