29R5914634 /00 MDSC-8527
4. Select one of the available main sources and confirm.
4.3.2 DisplayPort mode
About DisplayPort mode
The available DisplayPort (DP) modes for your display are:
• DP 1.2 SST
• DP 1.2 MST L:R: MST stream 1 on Left side/ MST stream 2 on Right side
• DP 1.2 MST R:L: MST stream 1 on Right side/ MST stream 2 on Left side
Please refer to the technical specifications for an overview of accepted video formats.
To select the DisplayPort mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the DP mode submenu.
4. Select one of the available DisplayPort modes and confirm.
4.3.3 Failover input
About failover input
This function allows the display to automatically switch to a failover (backup) source in case the main source is
missing. The display will automatically restore the main source once the signal is back.
The available failover inputs for your display are:
• None
• DVI
• SDI
• HDMI-1
• HMDI-2
The failover input can only be selected when both
1. the Auto search function is disabled (see “Main source”, page 28), and
2. the PIP/PBP Modes function is disabled (see “Picture-in-Picture (PIP)”, page 30 and “Picture-by-
Picture (PBP)”, page 30).
If any of both functions are enabled then failover will be disabled and made unavailable. As soon as
both functions are disabled again, failover will be enabled and made available again with the
selected failover input.
The failover input will be activated within about 7 seconds after the main source has been lost.
During the transition from main to failover input and vice versa, a text message is visible to inform
the user.
The main source can be changed while the failover input remains unchanged. During the selection
and synchronization of a new main source the failover function is temporary (7 sec) disabled.
To select the failover input
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Failover Input submenu.
4. Select one of the available failover inputs and confirm.
Advanced operation
