R5906113 /08 UDX62
Input specifications – HDMI Input
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate 25 – 600 MHz pixel clock
HDCP support • HDCP 1.x
• HDCP 2.2
• RGB 4:4:4
Color space • YCbCr 4:2:0
• YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
3D support • Field sequential 3D (Active 3D)
- Frame-packed
- Top Bottom progressive
- Side-by-side progressive
• Passive 3D not supported.
For future release • Interlaced support
Audio Not supported
Video timings
2
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
Native video timings • UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2400 @60 Hz
CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated
electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching
inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/
m can cause random flashes or temporary loss of the projected image.
As such, shielded CAT-6 cables with metal RJ-45 connectors are recommended; choose cable
length no longer than required and route HDBT cable optimally screened from possible sources of
electromagnetic emission.
Input specifications – HDBaseT inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate 25 – 297 MHz pixel clock
Color space • YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
Input & Communication
