Barco UDX

R5906113 /08 UDX 63
• 36 bpp
HDCP support HDCP 1.x supported on HDBaseT Input 1
Network support Yes, on HDBaseT Input 1
For future release • 3D support
• Interlaced support
Audio not supported
Video timings
progressive
2
Layout mode Supported formats
Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @25 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 2560 x 1600 @50 Hz
• Up to 2560 x 1600 @60 Hz
2 Column mode (2x1
layout)
• 1920 x 2160 @50 Hz
• 1920 x 2160 @60 Hz
• 2048 x 2160 @50 Hz
• 2048 x 2400 @60 Hz
Native video timings • UDX-U-series: 1600 x 1200 @60 Hz
• UDX-W-series: 1920 x 1200 @60 Hz
• UDX-4k-series: 3840 x 2160 @60 Hz
CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz) via the DP1.2
input, the quality of the cable must be adequate, in addition the length of the cable can also
influence the performance. In case there is an issue with one of these criteria the automatic link-
training initiated by the DP-standard may decide to switch to a lower resolution.
Input specifications – DisplayPort 1.2 input
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
Pixel rate Up to 600 MHz pixel clock
Color space • YCbCr 4:2:2
• YCbCr 4:4:4
• RGB 4:4:4
Color depth • 24 bpp
• 30 bpp
• 36 bpp
Data rate support • 1.62 Gbps: Reduced Bit Rate (RBR)
• 2.7 Gbps: High Bit Rate (HBR)
• 5.4 Gbps: High Bit Rate 2 (HBR2)
HDCP support HDCP 1.4
For future release • Interlaced support
Audio not supported
3D support • Field sequential 3D (Active 3D)
• Passive 3D not supported on this board.
Video timings
progressive
2
2D / 3D Layout Mode Supported formats
Input & Communication
