Barco UDX Installation Manual

R5906113 /08 UDX 81
4
5
Image 7-4
7. Install the data wire by plugging in the electrical connectors (connector J327, reference 1).
1
Image 7-5
8. Position the antenna (7) in the hole on the front side of the Communication module.
9. Secure the antenna wire by installing the lock washer and nut (8).
WiFi & GSM Module
