Instructions For Use
12.4 Probe Specifications
L-VA : Linear Vascular Access Probe
Frequency: 5 - 10 MHz
Elevation Focus: 1.8 cm
Maximum Scan Depth:
6.0 cm
Scan Width:  1.9cm
Lateral Foci:
12.5 Power Supply Specifications
Note: For 240 V applications use only center tapped 240 VAC single phase power as shown below.
A/C Adapter Specifications
Input Voltage: 100-240 VAC, 50/60 Hz
Input Current (Max): 2 Amps
Output Voltage: 15 VDC
Output Current (Max): 6 Amps
Image Depth Focal Depth
1.5 cm 0.6 cm
3.0cm 1.5 cm
4.5 cm
3.0cm
6.0 cm 5.0 cm
