Bartec POLARIS BASIC User Manual

POLARIS BASIC - for Zone 1/21
POLARIS Panel PCs 5.7" / 10.4" / 12.1"
Technical data
Technical data subject to change.
06/2017
EN 11/45
4.1.1 Characteristics POLARIS Panel PC 5.7"
Display
5.7" graphics-capable TFT colour display
262,144 colours
QVGA resolution 320 x 240 pixels
Brightness 400 cd/m
2
Visible surface approx. 116 mm x 88 mm
Contrast 400:1
Antireflection coating glass pane
Backlighting
CFL technology
Service life approx. 50,000 hours (at +25 °C)
Keyboard (short-stroke keys)
Alphanumeric key block
4 cursor keys
6 special keys
10 function keys able to be labelled with LEDs
Interface (Basic version)
1 x Ex e RS422/RS485
1 x Ex i USB for Ex i memory stick
Dimensions
(width x height x depth)
335 mm x 199 mm x approx. 130 mm
Wall cut-out
(width x height)
321 mm x 179 mm ± 0,5 mm
Weight
approx. 10 kg
4.1.2 Characteristics POLARIS Panel PC 10.4"
Display
10.4" graphics-capable TFT colour display
262,144 colours
VGA resolution, 640 x 480 pixels
Brightness 450 cd/m
2
Visible surface approx. 211 x 158 mm
Contrast 600:1
Antireflection coating glass pane
Backlighting
CFL technology,
Service life approx. 50,000 hours (at +25 °C)
Keyboard (short-stroke keys)
Alphanumeric key block
4 cursor keys
10 special keys
12 function keys able to be labelled with LEDs
Interface (Basic version)
1 x Ex e RS422/RS485
1 x Ex i USB for Ex I memory stick
Interface (optional)
1 x Ex i Supply module for
hand-held scanner
Dimensions (width x height x depth)
400 mm x 246 mm x approx. 130 mm
Wall cut-out
(width x height)
386 mm x 226 mm ± 0.5 mm
Weight
approx. 14 kg
