POLARIS BASIC - for Zone 1/21
POLARIS Panel PCs 5.7" / 10.4" / 12.1"
Installation
Technical data subject to change.
06/2017
EN 19/45
6.2.2 Installation as a System Solution in the Stainless Steel Enclosure
The POLARIS is available as a ready-made system solution in a stainless steel enclosure
e.g. for floor or wall mounting.
CSA approval
The CSA approval for the POLARIS series only includes the basic device POLARIS
BASIC.
Other system solutions and mounting systems (e.g. table mounting) have not been
tested and approved in accordance with CSA.
For POLARIS built into the enclosure door:
The open door must be supported and secured during the installation and servicing
phase. Otherwise the wall thickness specified may lead to the door sagging slightly
when open.
Selecting the location
CAUTION
Pay attention to wall and ground condition!
A sufficiently stable wall (e.g. concrete or limestone) or floor (e.g. concrete) must
be selected for securing the load-bearing system.
The structural stability of the wall or floor must be able to bear 4 times the weight of
the POLARIS as system solution.
The support arm system must be assembled using suitable mounting materials
(M12) (e.g. dowels or stud bolts).
Stainless steel enclosure "Standard" for floor and wall mounting
Type
(Width x Height x Depth)
Work steps
(1) Prepare supply and data line(s).
(2) Prepare installation on the basis of the drilling template (see illustration 8 - 9).
(3) Install supply and data line(s) in the base.
(4) Fasten the supporting system.
(5) Pull supply and data line(s) through the cable glands provided into the enclosure.
Ensure there is sufficient length.
(6) Mount the enclosure on the supporting system.
(7) Open the terminal compartments on the POLARIS and feed the supply and data
line(s) through the cable glands and wire them. Block unused terminal
compartments with a blanking plug.
(8) Close the door of the enclosure.
