POLARIS BASIC - for Zone 1/21
POLARIS Panel PCs 5.7" / 10.4" / 12.1"
Installation
Technical data subject to change.
06/2017
EN 17/45
– The POLARIS must be heated when at temperatures below 0°C. We furthermore
recommend protecting the display from the cold, e.g. with a door on the front of the
enclosure.
POLARIS with CFL backlighting
– The POLARIS must be heated when at temperatures below 0 °C. We furthermore
recommend protecting the display from the cold, e.g. with a door on the front of the
enclosure.
– The POLARIS should be heated when at temperatures below +10 °C to avoid the
service life of the backlighting being curtailed.
Outdoor installation
ATTENTION
Damage from condensation or overheating!
Avoid direct sunlight! Remedy: e.g. shelter with sufficient air circulation.
Remove condensation on the POLARIS immediately.
A POLARIS built into an enclosure must be heated and not removed
from the mains.
Equip the protective housing with breather.
6.2 Mechanical installation
CAUTION
This device is heavy (10-18 kg).
There is a risk of injury if it is lifted or moved incorrectly.
You will need help from others when transporting it.
Only qualified personnel, i.e. trained skilled specialists will have
specialised know-
how to be able to perform all the mechanical work. Familiarity with
and the technically perfect implementation of the safety instructions described in this
manual are preconditions for safe installation and commissioning.
6.2.1 Installation in 2G-/2D-enclosure
In order to guarantee the IP degree of enclosure protection = IP54 for installation in 2G
enclosures of Ex e type of protection (e.g. control equipment), and = IP6X for installation
in 2D enclosures in areas where combustible dusts exist - with “protection through the
enclosure” type of protection - the reinforcement frame should be used for fastening on
the front side.
A reinforcement frame is inserted between the retaining brackets and the enclosure
material for good transmission of the clamping force. This ensures even transmission of
force.
For POLARIS built into the enclosure door
The open door must be supported and secured during the installation and servicing
phase. Otherwise the wall thickness specified may lead to
the door sagging slightly
when open.
