29-30 9440300990
PROFIBUS Communication DECS-250
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Loss of Sensing
168
Float
R/W
Time Delay GG
Sec
0 - 30
Loss of Sensing
168
Float
R/W
Voltage Balanced
Level GG
%
0 - 100
Loss of Sensing
168
Float
R/W
Voltage Unbalanced Level
GG
%
0 - 100
81O
169
UINT32
R/W
Mode PP
No Unit
Disabled=0 Over=1
81O
169
UINT32
R/W
Mode PS
No Unit
Disabled=0 Over=1
81O
170
Float
R/W
Pickup PP
Hz
30 - 70
81O
170
Float
R/W
Time Delay PP
ms
100 - 300000
81O
170
Float
R/W
Pickup PS
Hz
30 - 70
81O
170
Float
R/W
Time Delay PS
ms
100 - 300000
81O
170
Float
R/W
Voltage Inhibit PP
%
5 – 100
81O
170
Float
R/W
Voltage Inhibit PS
%
5 – 100
81U
171
UINT32
R/W
Mode PP
No Unit
Disabled=0 Under=2
81U
171
UINT32
R/W
Mode PS
No Unit
Disabled=0 Under=2
81U
172
Float
R/W
Pickup PP
Hz
30 - 70
81U
172
Float
R/W
Time Delay PP
ms
100 - 300000
81U
172
Float
R/W
Voltage Inhibit PP
%
5 - 100
81U
172
Float
R/W
Pickup PS
Hz
30 - 70
81U
172
Float
R/W
Time Delay PS
ms
5 - 300000
81U
172
Float
R/W
Voltage Inhibit PS
%
50 - 100
Reverse Power
173
UINT32
R/W
Mode PP
No Unit
Disabled=0 Enabled=4
Reverse Power
173
UINT32
R/W
Mode PS
No Unit
Disabled=0 Enabled=4
Reverse Power
174
Float
R/W
Pickup PP
%
0 - 150
Reverse Power
174
Float
R/W
Pickup PS
%
0 - 150
Reverse Power
174
Float
R/W
Time Delay PP
ms
0 - 300000
Reverse Power
174
Float
R/W
Time Delay PS
ms
0 - 300000
Loss of Excitation
175
UINT32
R/W
Mode PP
No Unit
Disabled=0 Enabled=1
Loss of Excitation
175
UINT32
R/W
Mode PS
No Unit
Disabled=0 Enabled=1
Loss of Excitation
176
Float
R/W
Pickup PP
%
0 - 150
Loss of Excitation
176
Float
R/W
Time Delay PP
ms
0 - 300000
Loss of Excitation
176
Float
R/W
Pickup PS
%
0 - 150
Loss of Excitation
176
Float
R/W
Time Delay PS
ms
0 - 300000
Field Overvoltage
177
UINT32
R/W
Mode PP
No Unit
Disabled=0 Enabled=1
Field Overvoltage
177
UINT32
R/W
Mode PS
No Unit
Disabled=0 Enabled=1
Field Overvoltage
178
Float
R/W
Pickup PP
V
1 - 325
Field Overvoltage
178
Float
R/W
Time Delay PP
ms
200 - 30000
Field Overvoltage
178
Float
R/W
Pickup PS
V
1 - 325
Field Overvoltage
178
Float
R/W
Time Delay PS
ms
200 - 30000
Field Overcurrent
179
UINT32
R/W
Mode PP
No Unit
Disabled=0 Enabled=1
Field Overcurrent
179
UINT32
R/W
Mode PS
No Unit
Disabled=0 Enabled=1
Field Overcurrent
180
Float
R/W
Pickup PP
Amp
0 - 22
Field Overcurrent
180
Float
R/W
Time Delay PP
ms
5000 - 60000
Field Overcurrent
180
Float
R/W
Pickup PS
Amp
0 - 22
Field Overcurrent
180
Float
R/W
Time Delay PS
ms
5000 - 60000
Power Input Failure
181
UINT32
R/W
Mode GG
No Unit
Disabled=0 Enabled=1
Power Input Failure
182
Float
R/W
Time Delay GG
Sec
0 - 10
Exciter Diode Monitor
183
UINT32
R/W
Exciter Open
Diode Enable GG
No Unit
Disabled=0 Enabled=1
Exciter Diode Monitor
183
UINT32
R/W
Exciter Shorted
Diode Enable GG
No Unit
Disabled=0 Enabled=1
