DECS-250 Analog Expansion Module
Figure 32-3. Analog Inputs - Voltage Input Connections
Figure 32-4. Analog Inputs - Current Input Connections, Type II 2-Wire Circuit
AIN I+
AIN
–
AIN V+
AEM-2020
P0059-78
0
– 10 Vdc
Voltage
Transducer
