32-8 9440300990
Analog Expansion Module DECS-250
Figure 32-5. Analog Inputs - Current Input Connections, Type III 2-Wire Circuit
Figure 32-6. Analog Inputs - Current Input Connections, Type IV 2-Wire Circuit
External RTD Input Connections
External 2-wire RTD input connections are shown in Figure 32-7. Figure 32-8 shows external 3-wire RTD
input connections.
