Batavus Hybride - Saddle Adjustment and Types

10
Saddle5.
Saddle types
A B C
D E
A Height adjustment with frame bolt (see 5.2)
B Height adjustment with clamping ring (see 5.3)
C Height adjustment with quick coupling (see 5.4)
D Position adjustment with saddle bolt (model
with 1 or 2 bolts) (see 5.6)
E Position adjustment with quick coupling
(see 5.7)
• Watchoutforroughsurfaceswhenparkingthebicycletoavoiddamagingthesaddle.
• Saddlesurfacesmaycomeoffbecauseofweatherinuences.Useasaddlecovertopro-
tect the saddle.
