Adjust integrated stem (Aheadset)6.7
Tilting of the handle bars
1. Loosen the socket screws (A).
2. Tilt the handle bars to the required position using
thetwoboltsatthefront/ontop.
Make sure that the handle bars are exactly in
the middle.
3. Tighten the socket screws.
Adjust Batavus Ergo Grip6.8
1. Loosen the socket screw (A) a few turns.
2. Put the handle bars into the correct position.
3. Carefully tighten the socket screw.
Adjust the suspension fork6.9
Proportionally adjust the spring force using buttons (A)
and (B)*.
Some suspension forks have caps. You can easily
remove these using, for example, a coin.
Not all suspension forks can be adjusted.
The adjustable forks can be recognised by the mark
‘+’and‘–‘witharrow.
+ = tighter, so more rigid
- = more loose, so suspension is felt more clearly
* A and B are also available in notched models.
Here use, for example, a coin to turn them.
A
1
A
1
A
B
1
