Batavus Hybride - Position Adjustment with Saddle Bolt

13
Position adjustment with saddle bolt5.5
A
1
1. Loosen the bolt(s) (A).
2. Set the position (tilt).
3. Tighten the bolt.
A model with 2 bolts is available as well.
Position adjustment with quick coupling5.6
A
1
1. Openthequickcoupling(A).
2. Set the position (tilt).
3. Close the quick coupling.
