Technical data14.
Torques14.1
In order to prevent the thread from getting damaged or loosened while cycling, tighten the
bolts and nuts in accordance with the determined torques. The data in the table below are
general target values.
Item Torque [Nm]
Oftheboltsandnutsmentionedinthemanual.
Handle bars expander bolt 20 - 25
Dynamo bolt + self-locking nut 10
Saddle post bolt M8 20 - 25
Saddle post bolt M10 25 - 30
Stem bolt M6 for handle bars 12 - 13
Hubshaftnutsrear/SRAM 30 - 35
Hubshaftnutsrear/Shimano 30 - 40
Ergo Matic stem 25
Stem bolt M8 expander 15 - 20
Ergonomic grip 15 - 20
Caution:whentighteningboltsandnutsthecorrecttorqueisofmajorimportance.We
recommend you to consult your dealer for your own safety.
