Batavus Hybride - Height Adjustment with Frame Bolt

12
Height adjustment with frame bolt5.2
1. Loosen the bolt (A).
2. Adjust the height.
3. Tighten the bolt.
Height adjustment with clamping ring5.3
1. Loosen the bolt (A).
2. Adjust the height.
3. Tighten the bolt.
Height adjustment with quick coupling5.4
1. Loosen the quick coupling (A).
2. Adjust the height.
3. Tighten the quick coupling.
A
1
A
1
A
1
