Batavus Hybride - General Saddle Height Adjustment

11
Height adjustment, general5.1
Safety mark
Do not adjust the height of the saddle post beyond
the safety mark (A). The saddle post must be
inserted in the frame tube for more than 7 cm.
Sitting position
For a comfortable sit the procedure given below can
beuseful:
1. Put off your shoes.
2. Mount the bicycle.
3. Hold the crank in line with the seat tube.
4. Place your heel on the pedal.
5. You must just be able to stretch your leg.
A too high seat will make you slide on the sad-
dle and your back protest. A too low seat will
cause irritation at the back of your knees.
Set the suspension power of the saddle post
1. Take the saddle post with the saddle off the frame
tube.
2. Turn the socket screw (A) to set the suspension.
• turnclockwisetoincreasethetension
• turncounterclockwisetodecreasethetension
3. Re-insert the saddle post into the frame tube.
MAX
7 cm
1
1
A
1
