4.4 Signal Processing
4.4.1 Measurement Mode (Only O200.G, S)
With this parameter pre-defined modes can be selected to achieve optimal results without much trial and
error.
Parameter name
Short Description
Rights
Unit / Allowed values
Measurement Mode
Choose measurement mode for
different applications
rw
- High Speed
- Standard
- High Power
High Speed:
Ideal for fast moving objects. Sensors is adjusted for fastest response time. Detection ability identical to
Standard-Mode but with reduced ambient light immunity
Standard:
Standard setting with outstanding performance with the highest ambient light immunity.
High Power:
Twice the excess gain compared to Standard mode but with slower response time.
Reduced hysteresis due to better signal/noise ratio.
4.5 Input/Output Settings
4.5.1 Switching Output
Parameter name
Short Description
Rights
Unit / Allowed values
DI/DO Settings.OUT1 Circuit
Selection of circuit type
rw
- PushPull (default)
DI/DO Settings.OUT1 Mode
Selection of output source
(Default: SSC1)
rw
- None (SIO
deactivated)
- SSC1 (default)
- SSC4
