4.7 Quality Parameters
The O200 sensors offers quality values to give an idea about the reliability or trend of the process based on
the ratio of the current signal and the threshold or minimum required signal.
- Contamination indicaton
- Alignment indication
- Evaluation of process reliability
Parameter
name
Short Description
Rights
Unit /
Allowed
values
Quality Value
Same value as described in section 4.2.1.
The quality value represents the excess gain ration in %
100 = Exactly the amount of light needed for a switching
operation
200 = Twice the amount of light needed
O200.G, O200.S:
Quality = Strength of received light / Strength required
O200.R:
Quality = Intensity value / SSC1 SP1
ro
Quality Bit
Threshold
Sets the threshold for the quality bit value in % which is
mapped to the process data in (section 3.2.1)
The quality bit is directly connected to the weak signal
indication LED (section 4.6.2)
Default: 150
rw
4.8 Device Access Locks
Parameter name
Short Description
Rights
Unit /
Allowed
values
Parameter (write) Access
Lock
n/a
rw
True/False
Data Storage Lock
Deactivates the parameter server
functionality / does not overtake values
rw
True/False
Parametrization Lock
n/a
rw
True/False
Local User Interface Lock
n/a
rw
True/False
