Bit 8 to 15: Scale
Value is the exponent to the power of ten, applicable to the value of the Measurement Data Channel (MDC)
Example:
- Value of MDC 1000
- Unit m
- Scale -6
- Means 1000*10
-6
m or 1000 m
As O200 sensors only provide measuring values where no scale factor is required, the scale factor is set
fixed to 0 (zero).
Bit 16 to 31: MDC / Measurement Value
MDC stands for measurement data channel. Via this channel the distance value or the switch counts of
SSC1 or 4 can be read out as 16 bit integer value. See section 4.2 to learn how to configure the MDC.
3.2.2 Process Data-Out
This data is cyclically sent from the master to the sensor (MasterSensor).
IO-Link Process Data Output
Bit:
7
6
5
4
3
2
1
0
Find Me (Localization: LEDs
flashing)
Disable
Transmit LED
Bit 0: Disable Transmit LED
If set to true, the transmition LED is deactivated. The sensor will not deliver a measurement or switching
value. This can be useful to measure neighbouring sensors sequentially or to perform functional tests.
Bit 1: Find Me Function
Signalling e.g. by flashing LEDs on the sensor to locate and physically identify a sensor in a machine or
system. The signalling can be triggered, for example, from the engineering tool of the controller.
