Baumer TA202 - Limit Value P2 Assignment; Digital Output Logic; Decimal Point Settings for F1, F2, F3; Basic Display Assignment

TA202
www.baumer.com
43
Line 34 Assignment of the limit value P2
0 * upper limit value of F1
1 lower limit value of F1
2 upper limit value of F2
3 lower limit value of F2
4 upper limit value of F3
5 lower limit value of F3
Line 35
Output logic for digital output
0 * Both outputs as n.o. contacts
1 P1 n.c. contact, P2 n.o. contact
2 P1 n.o. contact, P2 n.c. contact
3 Both outputs as n.c. contacts
Line 36
Decimal point for F1
0 * no decimal point
1 0.0
2 0.00
3 0.000
Line 37
Decimal point for F2
0 * no decimal point
1 0.0
2 0.00
3 0.000
Line 38
Decimal point for F3
0 * no decimal point
1 0.0
2 0.00
3 0.000
(see line 21) with
measurement function 3, 4, 5, 6
59.59.99 min
99.59.59 h
Line 39
Assignment of the basic display (reset after 15 s)
0 * No switchover to the basic display
1 F1
2 F2
3 F3
4 SZ
5 P1
6 P2
Line 40
Code setting
0 * 0 No code
1...9999
Line 41
Assignment of the function key ( fast display changeover)
0 * Function keys not assigned
1 F1
2 F2
3 F3
4 SZ
5 P1
6 P2
