5.5.1. Denotationsforthedeckplan(withoptionalequipment)
Pos. Part/item Pos. Part/item
1 Anchor 21 Companionway with washboards and sliding lid
2 Bowttingwithanchor(Option) 22 Companionway sump
3 Anchorlockerlid 23 Halyardwinch
4 Anchorlockerlidlock 24 Jib winch
5 Anchorwindlass 25 Main sail winch
6 Gennakerboom(Option) 26 Cockpit table
7 Furlex(Option) 27 Steering console
8 Pulpit 28 Compass
9 Railing 29 Chartplotter(Option)
10 Pushpit 30 Rudder bearing
11 Cleats 31 Cockpit locker for life raft
12 Deck hatch 32 Shore power connection
13 Rig/mastbase 33 Gaslocker
14 Single organizer 34 Aftdeckshower
15 Jib track 35 Manual bilge pump
16 Twin organizer 36 Backstay chain plate
17 Tripleorganizer(2x) 37 Freshwaterller
18 Deck vent 38 Dischargedeckttingholdingtank
19 Handholdontheside 39 Dieselllertting
20 Jammer(halyards)
