Bavaria Vision 46 - AC System (230;110 Volt)

Owner‘s manual
32
Pleaseobservetheinstructionsofthemanufacturer:
The batteriesareAGM batteries, an absorbedglassmat battery has the electrolyteabsorbedin a ber-glass mat
separator.Whilethesebatteriesareoftencolloquiallycalledsealedlead–acidbatteries,theyalwaysincludeasafety
pressurereliefvalve.Asopposedtovented(alsocalledooded)batteries,aVRLAcannotspillitselectrolyteifitisin-
verted.BecauseAGMVRLAbatteriesusemuchlesselectrolyte(batteryacid)thantraditionallead–acidbatteries,they
are sometimes called an „acid-starved“ design.These batteries are well suited to marine applications.
6.6. ACSystem(alternatingcurrent230/110Volt)
The230/110Voltpanelservesasthecontrolunitwithconnectedshorepowerorthegeneratorrunning.Thesystemis
polarized.Thebelowimagedesignatesthesinglecontrollamps,switchesandbreakersonthe230/110Voltpanels.
Danger
» ThePanel230/110Vissuppliedwith230/110V~±5%,50/60Hzlinevoltage.2
» Potentiallylethalvoltagesarethereforestillpresentatsomepartsontherearofthispanel(in-
putB16/FI)-evenwhenthepanelhasbeenswitchedoffattheresidualcurrentcircuitbreaker.
» Measurementandserviceworktopanels301(12Volt)/Panel230/110Vmayonlybeperformed
byspeciallyqualiedpersonnel.
» Incorrectusageofpanels301(12Volt)/Panel230/110Vmaycauseseriousorevenlethalinju-
ries and considerable damage to property.
» The safety instructions and hazard warnings in the boatbuilder‘s operating manual take prece-
dencewhenusingpanels301(12Volt)/Panel230/110Volts.
» ObservetheapplicableaccidentpreventionandDINregulations(particularlyDINEN60204,
Part1)ortherespectiveregulationsinyourcountry.
» Beforeperforminganyserviceormaintenancework,alwaysswitchoffthepanel230/110Volts
at the residual current circuit breaker and disconnect it from the power supply.
» Secure the panel to prevent unauthorized reconnection of the power supply. Touching live parts
can lead to serious or lethal injuries.
