baxter AK 98 Training Material

35
PREPARING THE MACHINE | Concentrates
• Place the bottom port
of the
BiCart
cartridge
into the hole of the
lower latch.
• Turn the red concentrate connector clockwise and then remove it from the stand-by
port of the machine.
• Connect the red concentrate connector to a pick-up tube until a ‘click’ is heard.
• Place the pick-up tube into the proper acidic concentrate container.
• Confirm the concentrate combination.
• Press the release buttons.
• Open the upper latch of the
BiCart
cartridge holder.
• Pull it outwards and upwards.
• Open the lower latch.
• Bring down the upper
latch to align the hole
with the top port of the
BiCart
cartridge.
HC10139 |
