– 10 –
To adjust steam settings, press the corresponding arrows to enter the new values. The steam timer
cannot be adjusted during bake operation.
You can adjust the time remaining with the arrows. The set time remains unchanged unless you
“0” out the remaining time. If P20 (Restricted operator mode) is set for 1 the bake time cannot be
changed during the bake cycle.
If the door is opened at any time during the baking cycle, the TEMP, TIME, STEAM, and FAN
DELAY settings will pause. Close the door to resume all functions.
The FAN DELAY option turns o󰀨 the airow at the beginning of the baking cycle for the total time
entered in this window. The heat is o󰀨 while the FAN DELAY is activated.
The oven monitors the heating system by comparing the current oven temperature to the set
temperature. If a problem arises in the heating system or there is a heating system failure, both
temperature displays will ash after 15 minutes. If the problem continues, contact your authorized
Baxter service o󰀩ce.
BACK-UP CONTROL OPERATION (OPTIONAL)
If the main control panel ceases to function properly, baking can continue with the use of the Back-up
Controls, if equipped. The Back-up Controls are located behind the control door on rear wall of the
component panel.
To activate the Back-up Controls, ip the toggle switch to BACK-UP position. Temperature and steam are
now controlled by the thermostat dial and steam rocker switch, located on the back-up control panel. Set
the thermostat dial to the desired temperature. Once the oven has reached temperature, steam can be
injected by pressing and holding the steam rocker switch up to a maximum of 20 seconds. More than this
will cool down the oven and steamer excessively. Venting the oven must be done manually by opening
the door. The rack carrier will stop and lower when door is open. Close door after venting is complete for
rack carrier to lift and resume rotating. While in the backup mode the timer feature will not function.
SAFETY ALARM (STANDARD FEATURE, NO PARAMETER SETUP REQUIRED)
If the temperature at the probe is in the range of 570 - 600 degrees Fahrenheit for 10 seconds, the unit
will do the following:
1. Shut o󰀨 all features.
2. Sound an alarm.
3. Flash the OVEN TEMP display (actual temperature is displayed).
4. Display the letters ‘SHdn’ in the TIMER display.
The oven will remain in the shutdown mode until the 120VAC power is shut o󰀨. Turning on and o󰀨 the
circuit breakers will restore the oven to normal operation if the temperature is below 570 degrees.
Disconnect the electrical power to the machine and follow lockout / tagout procedures.
There may be multiple circuits. Be sure all circuits are disconnected.
Shut o󰀨 gas. Contact your authorized Baxter service o󰀩ce.
