DS-SERIES OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
53
From the configuration menu, select #1,
“Module IP Address,” followed by <cr>.
The DS73TP responds:
Enter Module IP address in dotted decimal form:
Enter the Module IP Address (Example:
200.4.3.50), followed by <cr>. The
DS73TP resumes the configuration
menu.Default Module IP Address is
0.0.0.0.
If you fail to enter the Module IP Address in
dotted decimal form, the DS73TP responds
again:
Enter Module IP address in dotted decimal form:
The DS73TP responds indefinitely with the
same request until the Module IP Address in
entered in the correct form.
IMPORTANT: The Module IP Address and the Dial-Up Address
must be different in order for the DS73 series module to function
correctly.
NOTE: There should be no active connections while configuring
the DS73TP module. The unit should be reset upon completion of
configuration.
Dial-UP The Dial-Up IP Address consist of four
IP Address bytes, each byte ranging from 0 to 255.
This parameter must be programmed
before the DS-Series can be accessed on
the network.
From the configuration menu, select #2,
“Dial-Up IP Address,” followed by <cr>.
The DS73TP responds:
