BayTech DS9 - Specifications

DS-SERIES OWNER’S MANUAL
APPENDIX A
65
APPENDIX A
SPECIFICATIONS
Table A.1
Base Unit DS71
Host
Module
DS71-
MD2
Host
Module
DS74
Peripheral
Module
DS73TP
Network
Module
I/O Modules 3, 6, or 9 N/A N/A N/A N/A
Power
Requirements
115VAC, 60Hz
0.3A or 230VAC
50Hz, 0.2A
N/A N/A N/A N/A
EIA-232 Serial
Port
8 pin
modular
connector
(MJ-45)
8 pin
modular
connector
(MJ-45)
(4) 8 pin
modular
connectors (MJ-
45)
8 pin
modular
connector (MJ-
45)
Environment
0° to 70°C
5% to 95%
humidity
0° to 70°C
5% to 95%
humidity
0° to 70°C
5% to 95%
humidity
0° to 70°C
5% to 95%
humidity
0° to 70°C
5% to 95%
humidity
Dimensions DS3:
16 3/4”w x 7”d x
1 3/4” h
DS6:
16 3/4”w x 7”d x
2 5/8”h
DS9:
16 3/4”w x 7”d x
3 1/2”h
N/A N/A N/A N/A
Weight 4 lbs. to 10 lbs. N/A N/A N/A N/A
Indicators 1 green power
LED
1 red port-
activity
LED
5 red
modem
activity
LEDs
4 red port-
activity LEDs
1 green LINK
integrity LED
1 red RX/TX
LED
1 red CX LED
Non-Volatile
Storage
8KB to hold
power-up
information
N/A N/A N/A N/A
