BayTech DS9 User Manual

DS-SERIES OWNER’S MANUAL
APPENDIX A
66
APPENDIX A
SPECIFICATIONS (Cont.)
Base
Unit
DS71 Host
Module
DS71-MD2
Host
Module
DS74
Peripheral
Module
DS73TP
Network
Module
Interface N/A EIA-232 EIA-232,
V.32bis
(14.4K bps)
MODEM
EIA-232 Ethernet, IEEE
802.3 complaint,
10Base-T
Transmission N/A Asynchronous Asynchronous Asynchronous N/A
Protocols N/A N/A N/A N/A PPP, TCP/IP,
ARP & ICMP
Frame Types N/A N/A N/A N/A Ethernet II and
SNAP (802.3)
Handshaking N/A CTS/DTR;
selectable
Xon/Xoff
TD, RD, CD,
MR, CX,
CTS/DTR;
selectable
Xon/Xoff
CTS/DTR;
selectable
Xon/Xoff
N/A
Baud Rate N/A 300, 600,
1200, 2400,
4800, 9600,
19.2K, 38.4K,
57.6K, 76.8K,
or 115.2K
300, 600,
1200, 2400,
4800, 9600,
19.2K, 38.4K,
57.6K, 76.8K,
or 115.2K and
14.4k (internal
modem)
300, 600, 1200,
2400, 4800,
9600, 19.2K,
38.4K, 57.6K,
76.8K, or
115.2K
N/A
Word Size N/A 5, 6, 7, or
8 bits
5, 6, 7, or
8 bits
5, 6, 7, or 8 bits N/A
Stop Bits N/A 1, 1 1/2, or
2 bits
1, 1 1/2, or
2 bits
1, 1 1/2, or
2 bits
N/A
Parity N/A Even, Odd, or
None
Even, Odd, or
None
Even, Odd, or
None
N/A
Buffer Size N/A N/A N/A N/A 256 KB
Mounting
(Optional)
Rack Mount
or Desktop
N/A N/A N/A N/A
Warranty
One year on
parts and
labor
One year on
parts and labor
One year on
parts and labor
One year on
parts and labor
One year on
parts and labor

BayTech DS9 Specifications

General

Brand	BayTech
Model	DS9
Category	Switch
Language	English
