Operating instructions B-Series
Version 2.4, En Page 30 of 81 21-10-2005
4.13 Direction of rotation
The direction of rotation must correspond with the rotation direction arrow on the pump.
Extra point(s) for attention with ATEX pumps.
P7.
B1.
Make sure that direction of rotation arrow is present.
Ensure direction of rotation protection (electrical/mechanical).
Dangers relating
to the software:
It is the responsibility of the employer to ensure that the safety
measures (such as the direction of rotation protection) and the
resulting action (such as the stoppage of the pump) are
appropriately included in the safety circuit.
To check the direction of rotation the motor must be briefly switched on. The motor may then not reach
operating speed. With an incorrect direction of rotation the connection on the terminal board must be
changed.
Safety devices
Make sure that if a safety device must be applied, the appropriate safety device is actually applied:
“Technical specifications B-Series”.
The operating instructions describe when a safety device must be applied.
Safety devices can be applied for aspects such as:
• Temperature
• Overpressure
• Underpressure
• Direction of rotation
• Oil level
• Overloading
• etc.
Extra point(s) for attention with ATEX pumps.
If a safety device is applied it must be suitable for the environment in which the
pump is located.
Dangers relating
to the software:
It is the responsibility of the employer to ensure that the safety
measures (such as the direction of rotation protection) and the
resulting action (such as the stoppage of the pump) are
appropriately included in the safety circuit.
