Operating instructions B-Series
Version 2.4, En Page 41 of 81 21-10-2005
7 Instructions for the assembly
This paragraph offers some advice for assembly.
When the pump is supplied as a free shaft end version, the user is himself responsible for the assembly of
the pump with drive gear. He must also take all measures to allow the pump (unit) to be correctly installed
and work properly.
When BBA Pompen BV supplies a complete pump unit the user must consult the operating
instructions. These contain instructions applicable for the pump (unit) specified.
With the movement of the complete pump/pump unit by
crane, the hoisting must belts must be applied by qualified
persons according to the prevailing rules for good hoisting
practice.
The hoisting equipment and hoisting belts must be
sufficiently strong to move the pump (unit). The hoisting
eye of the motor may not be used for moving the
pump/pump unit.
Because of the amount of available versions only general
instructions can be given here.
This is normally sufficient for experienced installation
technicians and competent transporters. When in doubt or if
there are questions, detailed information about the
pump/pump unit can be requested. See technical
specifications B-Series.
Extra point(s) for attention with ATEX pumps.
T1.
Make sure that the pump (unit) is mechanically well shielded during transport.
