Protocol specific information
DENNARD 2050 – Fixed at 9600,N,8,1 (adjust SW1 to suit input protocol)
Function TX1500 Procedure
Pelco Procedure
Display Dome Menu
1 #
SAVE PRESET 95
Display User Menu
2 #
GOTO PRESET 33
Display Technicians Menu
3 #
GOTO PRESET 94
Start current dome’s Sequence 001
1 PATROL
GOTO PRESET 97
Start ALL DOMES Sequence 001
2 PATROL
GOTO PRESET 98
Navigate through the dome menu using pan/tilt and issue GOTO PRESET 1 to select
current line.
MARK MERCER – Fixed at 9600,N,8,1 (adjust SW1 to suit input protocol)
Function TX1500 Procedure Pelco Procedure
180 Pan U turn
1 # or WASH
SAVE PRESET 95
Start current dome’s patrol
1 PATROL
GOTO PRESET 97
Start ALL DOMES patrol
2 PATROL
GOTO PRESET 98
SW2
SW2
