Samsung SCC641/643 dome and SCC421 camera from BBV
SCC641/643 dome
Connect dome RXD/+ to Converter TRA and dome RXD/- to Converter TRB.
Set the dome address using the SW500 switch to match the number of the camera input
of the TX1500. SW501 all off apart from 3 and 5 to select 9600 BAUD, SAMSUNG
protocol and FULL duplex. Ensure that any dome at the end of a daisy chained RS485
run are have switches SW501/1 and SW501/2 ON to terminate the RS485 terminated
and the intermediate domes have the SW501/1 and SW501/2 OFF.
The following functionality is provided.
Manual pan/tilt control with 16 speed steps.
Zoom with Manual Focus override.
Operating the Zoom will re-enable auto focus after manual adjustment
64 preset positions.
AUTOPAN can be started with the AUTOPAN key.
PRESET SCAN can be started using 1 PATROL.
PATTERN 2 can be started using 2 PATROL.
The patterns are defined from the dome menu which is accessed using 1 # as below.
Advanced Function TX1500 Procedure
Dome Menu ON
1 #
Dome Menu OFF
2 #
Dome Menu ENTER
3 #
Start PRESET SCAN
1 PATROL
Start PATTERN 2
2 PATROL
Start AUTOPAN
AUTOPAN
SCC421P Static camera
Connect the camera RS485 Data+ to Converter TRA and Data- to Converter TRB.
Ensure that BAUD RATE is set to 9600 and RS485 ADDR is set to match the video input
on the Tx1500 matrix. The buttons on the rear of the camera allow menu access.
Ensure that any camera at the end of a daisy chained RS485 run has the TERMINATION
switch ON and the intermediate camera have the TERMINATION switch OFF.
The following functionality is provided.
Zoom with Manual Focus override.
To allow manual focus set AUTO FOCUS in the menu to either ONEAF for MF.
ONEAF will cause an AUTOFOCUS after a zoom and MF is permanently in manual
focus mode.
Iris Open/Close.
SW2
