PANASONIC WV-CS850/860 (Added in V 4 software)
Control from BBV protocol only.
Function TX1500 Procedure
Show/Hide dome Menu
1 #
ENTER (whilst in menu)
2 #
ESCAPE (whilst in menu)
3 #
SPECIAL2 (whilst in menu)
4 #
Send PATROL RUN
1 PATROL
Send PATROL RUN to ALL DOMES
2 PATROL
Send AUTOPAN
AUTOPAN
BW MODE ON
89 PRESET
BW MODE OFF
88 PRESET
BW MODE AUTO
87 PRESET
Switch and dome settings:
VERY IMPORTANT! Ensure that each dome is configured BEFORE installation.
Output baud rate must be set to 19200,N,8,1 with SW2.
The dome must be set to Panasonic CONVENTIONAL protocol and the address set
accordingly.
The 4 way dome switch must be set to 4 wire telemetry with switches 2,3,4 OFF.
The RS485 cable requires termination at the end of the run by setting switch 1 ON.
The Panasonic CS850/860 protocol conversion is only available when controlled using
BBV RS485 telemetry. If another input protocol is selected using SW1 then the unit will
not function and all the LEDs will flash until BBV protocol is selected again.
Due to protocol issues, the response of an individual dome may become sluggish if
several domes are controlled simultaneously.
Connect TRA to RA(green) and TRB to RB(yellow).
9600,N,8,1 or 19200,N,8,1
