RS485 Star Card Manual V14 4Feb04.doc Page 23/29
Vicon Surveyor from BBV
Connect dome COMM_IN+ to Starcard/Converter TRA and dome COMM_IN- to
Starcard/Converter TRB.
Set the dome address using the DIL switch to match the number of the camera input of
the TX1500. Ensure that any dome at the end of a daisy chained RS485 run are have the
RS485 terminated and the intermediate domes have the RS485 de-terminated.
Select VPS telemetry using dome DIP DIL.
The following functionality is provided.
Manual pan/tilt control with 16 speed steps.
Zoom with Manual Focus override.
Operating the Zoom will re-enable auto focus after manual adjustment
64 preset positions.
3 tours can be started, tour 81 and 82 using 1 PATROL and 2 PATROL and tour 80 with
AUTOPAN.
The tours are defined from the dome menu
Advanced Function TX1500 Procedure
Display dome menu
1 #
MENU AP – ENTER
IRIS OPEN
MENU AI – ESCAPE
IRIS CLOSE
MENU AUX1
WASH
MENU AUX2
WIPE
Start TOUR 81
1 PATROL
Start TOUR 82
2 PATROL
Start TOUR 80
AUTOPAN
It is very important that once you have exited the dome menu you send a 1 PRESET to
inform the starcard that you are out of the dome menu.
SW2
