RS485 Star Card Manual V14 4Feb04.doc Page 18/29

Molynx 250/260 – Fixed at 9600,E,8,1 Control from BBV protocol only.

Function TX1500 Procedure

PRESET 1 – 32 As manual

WASH, WIPE, LIGHTS

AUX1 TOGGLE

1 #

AUX2 TOGGLE

2 #

RECEIVER INITIALISE

4 #

Notes:

Connect receiver + to Starcard TRA and receiver - to Starcard TRB.

Set the receiver address switches to match the number of the camera input of the

TX1500.

Molynx receivers can only be controlled when using BBV telemetry into the StarCard ie

from the BBV Tx1500 matrix.

Control of the receiver auxiliary relays is possible using the Tx1500 Wash, Wipe and

Lights keys. Additionally the AUX1 and AUX2 outputs can be toggled using 1# and 2#

respectively.

Up to 32 preset positions can be programmed and recalled.

A preset patrol is not supported.

SW2
