RS485 Star Card Manual V14 4Feb04.doc Page 14/29
VCL TP – When using Pelco input protocol
Advanced Function Pelco procedure
180 degree pan flip (U turn) SAVE PRESET 95
Program a privacy zone GOTO PRESET 33 followed by
PROGRAM 1-28 PRESET
Clear a privacy zone GOTO PRESET 94 followed by
PROGRAM 1-28 PRESET
Dome remote reset
(power cycle)
Head reset
Add preset position to the tours Saving a preset position adds the preset into the tour. (1
– 16 only)
Remove a preset from the tours PROGRAM 50 PRESET followed by
GOTO PRESET 1-16
Start preset tour 1 – high speed GOTO PRESET 97 (max speed with 10 second dwell)
Start preset tour 2 – slow speed GOTO PRESET 98 (speed 32 with 10 second dwell)
Start Learned tour 5 GOTO PRESET 99 (must be defined with SAVE
PRESET 56 as below)
Set Home functions
(fixed at 5 minutes)
PROGRAM 54 PRESET followed by
GOTO PRESET 1 = Enable to preset 1
GOTO PRESET 2 = Enable to tour 1 (fast)
GOTO PRESET 3 = Enable to tour 2 (slow)
GOTO PRESET 4 = Enable to learned tour (PRESET 99)
GOTO PRESET 5 = Disable home
Reset dome to factory. USE
CAUTION!!
This command will clear all
dome configuration including
preset positions.
SAVE PRESET 55 followed by
SAVE PRESET 55
Define learned tour 5 – START SAVE PRESET 56
Define learned tour 5 – STOP SAVE PRESET 57
Enable AUTO180 pan flip SAVE PRESET 58
