Vista PowerDome from BBV
Connect dome DATA IN A/+ to Starcard/Converter TRA and dome DATA IN B/- to
Starcard/Converter TRB.
Set the dome address using the DIL switch to match the number of the camera input of
the TX1500. Ensure that any dome at the end of a daisy chained RS485 run are have the
RS485 terminated and the intermediate domes have the RS485 de-terminated.
The following functionality is provided.
Manual pan/tilt control with 16 speed steps.
Zoom with Manual Focus override.
Operating the Zoom will re-enable auto focus after manual adjustment
64 preset positions.
3 tours can be started, TOUR 1 and 2 using 1 PATROL and 2 PATROL and LEARN
TOUR 1 with AUTOPAN.
The tours are defined from the dome menu which is accessed using 1 # as below.
Advanced Function TX1500 Procedure
Display dome menu
1 #
Menu – ENTER
2 #
Menu – ESCAPE
3 #
Start TOUR 1
1 PATROL
Start TOUR 2
2 PATROL
Learn 1 playback
AUTOPAN
SW2
To Next Page
