Meyertech ZVR-510 receiver with VICTA protocol from BBV telemetry only.
Connect receiver 422 RX+ to Converter TRA and 422 RS- to Converter TRB.
Set the receiver address to match the number of the camera input of the TX1500.
The following functionality is provided.
Variable speed Pan/Tilt – 8 speeds
Zoom/Focus
WASH, WIPE, LIGHTS auxiliary outputs
32 preset positions.
The Meyertech protocol supports 8 speeds for pan and tilt. If the head is to pan and tilt
simultaneously then the same speed is used for both axis. For example if the head is
moving left at say speed 4 and then the joystick is moved up the head will now move left
at the new tilt speed. This is not a problem with the converter but a limitation of the
Meyertech protocol.
SW2
