BD Veritor™ Plus Analyzer Instructions for Use
16
2.4 Printer Setup – Optional
Printer Unpacking and Setup
The BD Veritor™ Plus Analyzer can be configured to print test results to a connected printer. The printed language will match the currently
configured display language. The BD Veritor™ Plus Analyzer supports only specific printer models. Contact your BD representative to
obtain a list of compatible printer models and operating instructions. A USB 2.0 On-The-Go micro-A to B cable, or USB On-The-Go adapter,
is required. The cable may be purchased from computer supply retailers or may be ordered from BD under catalog number 443907.
For unpacking and setup instructions, or information about ordering replacement paper, refer to the instructions provided with the printer.
The printer is connected to the BD Veritor™ Plus Analyzer as follows:
1 Connect the USB B end of the USB cable to the corresponding port on the back of the printer.
2 Connect the USB micro-A end of the USB cable to the corresponding rectangular port on the back of the BD Veritor™ Plus Analyzer.
2.5 Module and Accessory Specifications – Optional
NOTE
The BD Veritor™ Plus Analyzer will only print test results when the printer is connected and powered on during the test
procedure. Due to data security considerations, test results cannot be recalled for subsequent printing. Prior to initiating
testing, ensure that the printer paper supply is adequate to support the test volume.
Optional Modules and Spare Parts BD Catalog Number
BD Veritor
™ InfoScan
256068
BD Veritor™ InfoWiFi module 445010
BD Veritor
™ Plus Connect
444881
BD Veritor™ Plus Analyzer Verification Cartridge 256047
BD Veritor™ Plus AC Power Adapter 445201
BD Veritor™ System USB Cable 445202
BD Veritor™ System Printer Cable 443907
Module Environmental Specifications
Operating Conditions
Ambient Temperature 15.0–30.0 °C (59–86 °F)
Ambient Humidity Up to 85% RH, non-condensing
Ambient Light 0–3,000 lux, uniform illumination
Ambient Environment Indoor Use Only
