BD Veritor™ Plus Analyzer Instructions for Use
18
3 Depress the locking tab on the module bay cover.
4 Slide the module bay cover off of the Analyzer. The module bay cover should be stored in a secure location.
5 Remove protective plastic cover from the module interface pins if present.
6 Align the module alignment features to the Analyzer track.
7 Slide the module into the Analyzer until an audible click is heard.
8 The Analyzer is now ready for operation. See section 4.6 for optional configuration instructions.
2.7 BD Veritor™ Plus Connect Set Up – Optional
The BD Veritor™ Plus Connect accessory utilized together with a barcode reader equipped module allows secure transmission of test
results to a facility LIS. Additional IT setup is required in order to install and utilize the BD Veritor™ Plus Connect accessory. To create or
troubleshoot this connection, please contact your local BD representative. Installation instructions for site IT staff are further detailed in
documentation included with BD Veritor™ Plus Connect.
2.8 BD Veritor™ InfoWiFi Module Setup – Optional
The addition of the BD Veritor™ InfoWiFi module enables the Analyzer to capture barcoded information and integrate it into the test record.
It then allows secure transmission of test results to a facility LIS. The USB cable included with the BD Veritor™ InfoWiFi module can be
used to connect the Analyzer to the BD Veritor™ Plus Connect. In order to complete the connection to a wireless network, additional IT
setup is required. Installation instructions for site IT staff are further detailed in documentation included with BD Veritor™ InfoWiFi.
To install InfoWiFi module:
1 Turn off the Analyzer power.
2 Turn the Analyzer upside down.
3 Depress the locking tab on the module bay cover.
4 Slide the module bay cover off of the Analyzer. The module bay cover should be stored in a secure location.
5 Remove protective plastic cover from the module interface pins if present.
6 Align the module alignment features to the Analyzer track.
7 Slide the module into the Analyzer until an audible click is heard.
WARNING
ELECTRICAL EXPOSURE HAZARD. DO NOT TOUCH THE ELECTRICAL CONTACTS INSIDE THE MODULE BAY.
CAUTION
Ensure that the power button is not accidentally pressed while the Analyzer is upside down.
Power to the Analyzer should remain off during module installation.
WARNING
ELECTRICAL EXPOSURE HAZARD. DO NOT TOUCH THE ELECTRICAL CONTACTS INSIDE THE MODULE BAY.
